New CAN FD inter-controller communication standard enabling cooperation with up to 64 additional gen-sets/mains/tie controllers
Keeping your business and data as safe as possible, meeting the ISA 62443 level 2 – level 3 security requirements
Hot-swap redundancy enabling a redundant unit to take over in case the primary controller fails, helping to minimise solution downtime*
CAN bus redundancy ensuring that a redundant CAN line be created and take over in case of CAN failure*
Modbus Client which can initiate Modbus communication and control 3rd party devices*
Large built-in PLC interpreter with the use of ComAp’s free PLC Editor
Compatible load/VAr sharing and power management with other ComAp solutions
Dynamic spinning reserve helping to deliver maximum amount of available energy from photovoltaics
Multi ECU (Electronic Control Unit) enabling communication with more independent J1939 devices such as Engine Control Unit, AVR modules, Breaker, etc.
Built-in CAN bus logger and event-based history for easy and fast troubleshooting
User-defined protections and setpoints on top of default protection
AirGate 2.0 for easy connection to your equipment remotely, without worrying about your asset’s IP address
More precise measuring with a True Root Mean Square measurement feature
Remote control and monitoring of your gen-set operations with WebSupervisor, our cloud-based fleet management tool
Secure user management
Droop regulation allowing load and Var sharing when the inter-controller’s communication is lost
Peak shaving for limiting the import from the mains (e.g. due to higher prices)
Load shedding ensuring the most important loads are running even when there is a lack of power
Start-up synchronisation to minimise the paralleling start sequence time and get the gen-set system up and running with minimum possible delay
Automatic Mains Failure that ensures automatic start of gen-sets and minimises downtime
A wide range of plug & play displays with automatically generated content that can be easily edited in our free Screen Editor or InteliSCADA
